IDC Connectors with Double-Contacting

inkl. 19 % MwSt. zzgl. Versandkosten

Artikelnummer: IKDTxx1xxG075 Kategorie:

Beschreibung

IDC Connectors with Double-Contacting

– Safe double contact area
– High quality version with stamped contacts
– UL approval
– Tin plated shell
– Used for difficult contacting in the cutting/fixing area

Technical Data

Nominal current AWG 24: 1,5 A / AWG 26: 1 A
Test voltage 1 KV / AC
Temperature range -20° C to +105° C
Plastic material Thermoplast UL 94 V-0



Dimensions

1-IKDT09154G2-DS_01
