CAN bus Bus Connectors
CAN bus Bus Connector Axial
Plug&Play M12
The simple and reliable connection and the faultless data transfer for CAN bus with plug & play bus connectors with two M12 connection interfaces. Bus connection with 100% tested bus connectors and ready-made M12 CAN bus cables. Easy plug-in of the new Provertha bus connector and plug-in of the M12 bus cables and the play of the CAN bus follows immediately. The 180° cable outlet of the Axial version allow the application especially in installation conditions with two close stacked interfaces .
Technical features
- Cable outlet 180° to D-Sub mating interface for stacked interfaces
- Fault-free CAN bus connection achieved by M12 connectors with A-coding for the CAN bus cable connection
- Reliable quick and simple CAN bus connection within a few seconds
- Easy installation without special knowledge
- Entirely shielded zinc die-cast housing for EMC/RFI-proofness with special shielding geometry at the housing
- Switch can be operated externally to activate the bus termination (switch can be operated internally for EMC/RFI-proof solution)
- Switch ON/OFF position visible from front side
- Locking: Allen key screw UNC 4-40
- 100% tested bus connectors for high functional reliability
