Description

Bus connector Axial external cable clamp connection

Axial PROFIBUS Bus connector external cable clamp

The easy and reliable connection for the fault-free data transmission are secured by bus connectors with external cable clamp which guarantee a safe strain relief and shield transition of the Profibus cable.
The axial construction allows the application especially in installation situations with two interfaces on top of each other.

Technical features

– Axial cable connection: 180° towards the D-Sub mating direction

– Effective 360° EMI/RFI shielding

– Version for railway technology and special EMV requirements with completely closed hf-dense full-metal housing and 360° EMI/RFI crimp flange system

– Completely shielded die-cast zinc housing for EMI/RFI safety with a special shielding geometry at the housing

– Easy and fault-free connection due to coloured clamps with letters for the respective Profibus wire

– Vibration-proof, easy and fast due to cage clamp

– Flexibility at the outer cable diameter due to cable clamps for different cable diameters, for example drag chain cables

– Lever externally operable for activating the bus termination

– ON/OFF.position of lever visible from the front

– Programming/diagnosis option with second D-Sub

– Latching: knurled screw UNC 4-40

– 100% tested bus connector for high reliability
