M12 SMT Ruggedized 90° X-Code

Description

Installation height 14 mm and functionally reliable with high mechanical requirements

Name: M12 SMT Ruggedized 90° X-Code
SKU: 266942
Availability: InStock

– Design for fully automatic SMT process

– Female versions

– Shielded and unshielded versions –

– Installation height: 14 mm

– Installation height suitable for use next to RJ45 interfaces or as a replacement for RJ45 interfaces for
outdoor switch versions

– Square design with 4 mounting/ground angles

– Optimized routing in all 4 directions possible

– Spring-elastic contact design protects against contacts breaking off under high stress

– High-temperature-resistant insulating body and suction PAD

– Tape packaging

– Coding position: 0°

– Other coding positions upon request

Technische Daten / Technical Data
cable
Protection class	IP 67 (only screw-locked)
torque	max. 0,8 Nm (M12x1 Kabelschraube )
thread type
connector type
Tightening torque	3 – 4 Nm (M14x1, Verriegelung)
Locking	Siehe Zubehör
Anschlussart	SMT
Koplanarität	< 0,1 mm
Reflow-Löttemperatur JEDEC J-STD-020C	20 – 40 sec bei 260° C
Datenübertragungseigenschaften	Cat 6A
Datenpbertragungsrate	Bis zu 10Gbit gemäß IEC 802.3an
Connector	M12 acc. to IEC 61076-2-109
Coding-Pin count	X-8
Temperature range	-40° C – + 125° C
Rated voltage	48 V
Current rating	0,5 A
Pollution degree	3
Contact resistance	≤ 10 mΩ
Insulation resistance	≥ 100 MΩ
Mechanical lifetime	≥ 250 mating cycles
Surge voltage category	III
Materialien / Materials
Sealings	Siehe Zubehör
RoHS und REACH	konform
Insulator body	Thermoplast UL 94 V-0
Contact material	Cu alloy
Contact plating	Ni/Au
